| Series | Part Name | Size(mm) | Inductance | Rated Current | Spec. | |||
|---|---|---|---|---|---|---|---|---|
| A | B | C | uH | A | ||||
| TWHC |  | TWHC0603 | 1.8 | 1.2 | 1.0 | 0.47~10.0 | 0.40 ~ 1.80 |  |
| TWHC0805 | 2.4 | 1.65 | 1.2 | 1.0~100 | 0.10 ~ 1.40 | |||
| TWHC1008 | 2.9 | 2.54 | 2.0 | 0.22~100 | 0.11 ~ 2.60 | |||
| TWHC1210 | 3.6 | 2.9 | 2.4 | 0.39~1000 | 0.05 ~ 3.00 | |||
| TLQH | | TLQH20L | 2.0 | 0.8 | 2.0 | 1.0~22.0 | 0.40 ~ 1.42 | |
| TLQH20 | 2.0 | 0.8 | 1.8 | 0.1~120.0 | 0.02 ~ 4.24 | |||
| TLQH25L | 2.5 | 1.0 | 2.5 | 1.0~22.0 | 0.46 ~ 1.90 | |||
| TLQH25 | 2.5 | 0.8 | 2.8 | 0.2~220.0 | 0.09 ~ 0.35 | |||
| TLQH32 | 3.2 | 1.2 | 3.5 | 0.1~1000 | 0.03 ~ 0.70 | |||
| TLQH43 | 4.3 | 1.8 | 4.2 | 1.0~470.0 | 0.09 ~ 1.08 | |||
| TLQH56 | 5.0 | 1.9 | 6.5 | 0.1~10000 | 0.05 ~ 6.00 | |||
| TWHF | | TWHF0402 | 1.27 | 0.76 | 0.61 | 1.0~120 | 0.05 ~ 1.36 | |
| TWHF0603 | 1.8 | 1.2 | 1.02 | 1.2~470 | 0.08 ~ 0.70 | |||
| TWHF0805 | 2.4 | 1.65 | 1.45 | 2.8~2700 | 0.16 ~ 0.80 | |||
| TWHF 1008 | 2.9 | 2.54 | 2.03 | 10.0~10000 | 0.15 ~ 1.70 | |||
